Convenient and precise rung-by-rung height adjustment in a grid of 280 mm.
Both parts of the ladder can also be used separately as single ladders for Order Nos. 44834 and 44820.
Robust extruded-section triangular rungs with step horizontal in working position.
High strength, non-twist connection between rungs and stiles.
Positive-locking extruded aluminium section guide fittings.
Rung hooks and locking tabs secure the sections together during use and transport.
Integral stabiliser bar that gives a far greater footprint and therefore unparalleled stability.
Replaceable 2-component plastic end caps ensure secure positioning without the risk of slipping.
External width of lower ladder: 420 mm.
Complies with EN 131.
|
Code
|
No. Of
Rungs
|
Closed
Length
|
Extended Length
|
Stile Dimension
|
Stabiliser Bar Width
|
Weight
|
|
02401
|
2 x 8
|
2.42m
|
3.80m
|
58mm
|
0.80m
|
9.3kg
|
|
02402
|
2 x 10
|
2.98m
|
4.92m
|
68mm
|
0.90m
|
11.3kg
|
|
02403*
|
2 x 12
|
3.54m
|
6.05m
|
68mm
|
1.0m
|
15.4kg
|
|
02404*
|
2 x 14
|
4.10m
|
7.17m
|
85mm
|
1.10m
|
17.8kg
|
|
02405*
|
2 x 16
|
4.66m
|
8.29m
|
85mm
|
1.20m
|
21.5kg
|
|
02406*
|
2 x 18
|
5.23m
|
9.17m
|
85mm
|
1.20m
|
23.9kg
|
|
02407
|
3 x 8
|
2.41m
|
5.25m
|
68mm
|
0.89m
|
15.3kg
|
|
02408
|
3 x 10
|
2.97m
|
6.65m
|
73mm
|
1.08m
|
19.2kg
|
|
02409*
|
3 x 12
|
3.53m
|
8.33m
|
85mm
|
1.20m
|
24.2kg
|
|
02410*
|
3 x 14
|
4.09m
|
9.45m
|
85mm
|
1.20m
|
26.9kg
|
* Ladders greater than 3m in closed length may incur additional carriage charge. You will be contacted prior to despatch to confirm costs.
