Features:
Integrated hand protection on the motor ensures a high degree of user-friendliness and provides you with safety during operation. The soft grip enables you to work with low vibrations. This means you can always expect consistent, oxide-free results. Regardless of whether you are processing straight sheets, T-beams or tubes. The surface roughness remains low.
The 2-speed gearbox guarantees perfect results to match the material thickness, strength, and type of workpiece.
The extremely powerful motor ensures a high degree of durability.
Integrated hand protection on the motor provides you with a high degree of safety when working.
It is quick and easy to adjust the optimal settings for the chamfer height and sheet thickness.
You can use the carrier for various angles between 20° and 55°.
Applications:
For straight edges and radius edges: welding seam preparation on outer and inner contours. With interior cutout diameters from 130 mm. Also for T-beams and double T-beams.
Tubes: welding seam preparation on tubes with an inside diameter from 30 mm.
Specification:
Max. chamfer length steel: 400n/mm2: 15mm, 600n/mm2: 9mm, 800n/mm2: 6mm
Smallest radius: 55mm
Working speed: 2m/min
Stroke rate at nominal load: 370 1/min
Nominal power consumption: 2600W
Sheet thickness: 4mm – 160mm
Weight: 19.2kg
Included as Standard: High-Tensile Cutting Tool, Chip Box, Handle Base, Tube-Shaped Handle, Roller Holder, Hexagon-Head Screw M10 x 20 – 10.9 DIN 933, 2 x Hexagon-Head Screw M10 x 25 – 10.9 DIN 933, Wrench, 6mm Allen Key, 500ml Oil, Tube of Grease, Grease Gun & Setting Gauge.
5 Years Warranty on all Trumpf Power Tools when registered.
