Mafell KSS50 18M BL 18V Cross-Cut Circular Saw – Body

Manufacturer: Mafell

• The versatility of the Mafell KSS 50 18M BL Cross-Cutting system means that it can be used as a cross-cut saw, plunge-cut saw, shadow gap saw or conventional portable circular saw.




  Read more

  Features:

  Thanks to the unique tilting system, a cutting depth of 42 mm (including rail) is always available in the angle range from 0° to 45°.

  The machine can be removed from the cross-cut track at the single press of a button, allowing its use for the full range of applications offered by the K 55 cc.

  The rubberized underside ensures a good grip on the work and avoids damage to the surface.

  This tool works on the 18V CAS Cordless Alliance System battery platform, where multiple brands including Mafell and Lamello, use Metabo battery technology.

  Applications:

  Cross cuts with guide.

  Rip cuts and cross-cutting.

  Plunge cuts and recesses.

  Compatible materials include solid wood, board materials, insulating materials, doors, worktops and internal finishing and renovation materials.

  Specification:

  Voltage: 18V

  Blade Size: 168mm x 20mm (Diameter x Bore)

  Cutting Depth with guide rail at 0°: 0 – 52mm

  Cutting Depth without guide rail at 0°: 0 – 58mm

  Cutting Depth with guide rail at 45°: 0 – 42mm

  Cutting Depth without guide rail at 45°: 0 – 48mm

  Cutting Length: 407mm

  Tilting range: 0 – 45°

  Angle cuts: -60° – +60°

  Weight with cross-cutting rail: 3.2 kg

  Included as Standard: TCT Saw Blade, 400mm Guide Track & Carry Case.

  3 Years Warranty on all Mafell Power Tools when registered.
