Leica NA320 Automatic Construction Optical Level

Manufacturer: Leica

• The Leica NA320 is a robust optical level – engineered to handle daily levelling tasks with the highest precision and accuracy while its simple design means quick and easy measurements with high quality results.




  Read more

  Features:

  Upright telescope image with 20x magnification.

  2.5mm standard deviation for 1km double levelling (ISO17123-2).

  Distinctive design and proven technology, inside and out.

  Simple handling for quick and accurate measurements.

  Unique design and highest quality of results for levelling needs.

  Manufactured for the most rugged sites and the harshest conditions.

  Specification:

  Accuracy/km Double-Run Leveling: 2.5mm

  Magnification: 20x

  Objective Aperture: 36mm

  Shortest target distance from instrument axis: < 1.0 m

  Telescope Field of View at 100 m: < 2.1 m

  Telescope Multiplication Factor: 100

  Compensator Working Range: ±15′

  Compensator Setting Accuracy: < 0.5’’

  Sensitivity: 8’ / 2 mm

  Horizontal Graduation: 360°

  Horizontal Graduation interval: 1°

  Weight: 1.5kg

  Included as Standard: Hard Carry Case.

  3 Years Warranty on all Leica Measuring Equipment when registered.
