Increased Productivity. Deburring, Bevelling and Radiuses are significantly expedited when compared with traditional methods thanks to the innovative patented design of the Inox cutter heads. The cutting surfaces ‘precise shape and angle enable swift and effortless metal removal. The outcome is an instant flawless smooth bevel or radius, eliminating the need for additional finishing when using the Bevel Mate® concept.
A Safer and Healthier working environment. The chip taken from the edge of the material is relatively larger and heavier which causes them to drop to the ground immediately rather than ending up in the air and the machine as fine dust. The Bevel Mate® concept also provides a reduction in sparks and adds minimum heat into the metal thus reducing the possibility of hazardous smoke or fume formation.
Minimum physical effort is required. Unlike working with plasma torches, grinding discs, sanding discs, or machines with inserts the machine and it’s Inox bevel heads handle the work effortlessly. Thanks to its ergonomic design and light weight the Bevel Mate® concept demands minimal physical effort during operation. The machine sits on the work piece during rounding and bevelling tasks, with the user’s primary function only being machine guidance.
The machines offer exceptional flexibility and are comfortable to hold, easy to maneuverer and provide a lightweight user experience with a weight of only 2.46kg. The Bevel Mate® EBA Inox concept enables rapid bevelling, rounding, and deburring of sheet metal edges and in hole diameters starting from 16mm
The Bevel Mate® concept also allows for emission free processing, the material being processed remains relatively unchanged from any additional heat input and remains free of oxidization with no sparks.
Consistent quality. The Bevel Mate® concept attains an unparalleled uniformed cutting pattern by maintaining constant contact with the metal. It effectively prevents discolouration as it cuts the metal without adding any additional heat and with minimal sparking. This distinctive cutting pattern sets the Bevel Mate® concept apart from other processes including machines that utilize carbide inserts.
Cutters supplied separately.
Specification:
Input: 1100 Watt
No Load Speed: 1100 – 3600 rpm
Available radius cutters: R2 – R3 – R4 – R6
Available bevel heads: 30°- 37,5°- 45°
Maximum bevel depth: 8mm
Minimum hole diameter for bevelling: 41mm
Minimum hole diameter for radiuses: 22mm
Weight: 5.65kg
