Bessey GH Lever Clamp

Manufacturer: Bessey

• Greater reserves of power, thanks to optimised rail profile, for even clamping force build-up, especially under maximum utilisation of the clamping range.




  Read more

  Features:

  Clamping Force up to 8500 N.

  Quick . . . 5 x Faster.

  Greater reserves of power ‚ thanks to optimised rail profile.

  Vibration Resistant.

  Non-slip trigger release.

  Specification:



  22011

  Clamping Capacity: 200 mm

  Throat depth: 100 mm

  Rail section: 22 mm x 8.5mm

  Clamping force: up to 8,500N

  Weight approx: 1.11 kg

  22012

  Clamping Capacity: 250 mm

  Throat depth: 120 mm

  Rail section: 24.5 mm x 9.5mm

  Clamping force: up to 8,500N

  Weight approx: 1.44 kg

  Code	Rail Section (width)	Rail Section (thickness)	Clamping (opening)	Throat (depth)	Clamping (force)	Weight (approx.)
  22011	22mm	8.5mm	200mm	120mm	8,500 N	1.11kg
  22012	24.5mm	9.5mm	250mm	120mm	8,500 N	1.44kg
